Product Dimensions 32.5"h x 17.75"w x 22.5"d
To ensure consistently clean items, this stainless steel blade rotates at 3,600 RPM to pulverize food particles and helps to prevent large particles from clogging the wash arms. A beam of light measures soil levels and water temperature to adjust to the ideal cycle time.Read More
Great for 34” counter top heights and raised subfloors
A beam of light measures soil levels and water temperature to adjust to the ideal cycle time
To ensure consistently clean items, this stainless steel blade rotates at 3,600 RPM to pulverize food particles and helps to prevent large particles from clogging the wash arms
Expect exceptionally clean table-ready dishes with powerful wash arms
General Specs | |
| Product Weight (lbs.) | 71 |
| Color | Stainless Steel |
| Appliance Fit Width (cm.) | 45 |
| ENERGY STAR Certified | Yes |
| Delay Wash (Up to hours) | 12 |
| Depth (in.) | 22.5 |
| Height (in.) | 32.5 |
| Noise level (dB) | 47 |
| Tub Material | Stainless Steel |
| Width (in.) | 17.75 |
| Manufacturer Warranty | 1 Year Parts & Labor |
| Appliance Fit Width (in.) | 18 |
| Sanitize Option | Yes |
| Smart Compatible | No |
| Color Finish Name | Stainless Steel |
| Number Of Place Settings | 8 |
| ADA Compliant | Yes |
| Cut Out Width | 17.75 |
| Cut Out Height | 32.5 |
| Dishwasher Type | Built-In |
| Control Panel Type | Top |
| Cut Out Depth | 22.5 |
| Width (cm) | 45.09 |
| Height (cm.) | 82.55 |
| Depth (cm.) | 57.15 |
| Product Weight (kg) | 32.20 |
| Cut Out Depth Centimeter | 57.15 |
| Cut Out Width Centimeter | 45.09 |
| Voltage | 120 |
| Frequency | 60 |
| Amp | 8.9 |
| Cut Out Height Centimeter | 82.55 |
| Sound Rating Range | Quieter |
| Dishwasher Features | Food Disposal, Sensor Wash |
| Third Rack | No |
Features | |
| Door Liner | Stainless Steel |
| Control Type | 4 Pushbuttons Fully Integrated Electronic Top Controls |
| Dishwasher Control Features | 3 Digit Countdown Display with 1 "Clean" light / 1 "Sanitized" light Cycle Progress Indicators Audible End-of-Cycle Signal Cycle Countdown Last Cycle Memory Start/Reset Pad |
| Wash System | 3-Level Standard |
| Wash System Features | Automatic HotStart Automatic Temperature Control Dual Pump Flood Control System Piranha™ Hard Food Disposer |
| Sensor | Clean Sensor |
| Wash Arms | 2 with Upper Nozzle |
| Water Filtration System | 3-Stage Manual Clean Filtration |
| Dispenser | Rinse Aid with Indicator and Adjustment |
| Dishwasher Cycles | Auto Sense Heavy Wash Light Wash |
| Number of Options | 5 |
| Dishwasher Options | Child Lock Delay Start 1-12 Hr. Sani (NSF 184 Certified) Start/Reset TempBoost |
| Rack Features | 1 Piece Mid Silverware Basket w/ 1 Cell Cover 1 Plastic Utility Shelf - Upper Ball-Tipped Tines Fold-Down Tines - Lower Stem Safe |
| Racking System | Gray |
| Upper Rack | 1 Rack handle Adjustable Nylon |
| Lower Rack | 1 Rack handle Nylon |
| Dishwasher Drying Features | Condensate Dry |
| Leveling System | Leveling Legs |
| Latch | Center Pull |
| WiFi Connect | Optional (Requires part no. PBX10W00Y0) |
| Connected Capabilities | Amazon Alexa IFTTT The Google Assistant |
| Exterior Style | 18" Wide |
Appearance | |
| Door Style | Stainless Full-Length Flat Door |
| Handle | Pocket Handle |
| Handle colour | colour-Matched |
| Handle Design | Recessed |
Economical/Quiet | |
| Motor Type | Single Speed |
| Outer Wrap | U-Blanket |
| Door Insulation | Insulation Mastic |
Weights and Dimensions | |
| Cabinet Width | 18 in |
| Height w/ Legs Retracted - Minimum Height | 32 1/2 in |
| Height w/Legs Extended - Maximum Height | 34 5/8 in |
Power/Ratings | |
| Calrod Heater Watts | 1100 |
